TP-Link Tapo H500 Smart HomeBase | Local Storage Security Center
TP-Link Tapo H500 | Smart HomeBase
Description:
The TP-Link Tapo H500 Smart HomeBase is a powerful hub for managing home security cameras and smart devices from one secure location. The device supports up to 16 Tapo cameras and provides reliable local storage thanks to its built-in 16GB eMMC memory, eliminating the need for monthly cloud storage subscriptions.
With an HDMI output, the Tapo H500 allows direct connection to a TV or monitor to view live cameras and multiple camera feeds, making real-time monitoring easier and more convenient for homes, offices, and retail environments.
The Smart HomeBase also functions as an integrated smart home control center, supporting up to 64 smart devices such as sensors, alarms, and switches. It acts as both a controller and a bridge, enabling seamless integration with modern smart home systems.
For long-term video recording, the Tapo H500 supports the addition of a 2.5-inch SATA HDD or SSD internal hard drive, allowing you to store video locally for extended periods according to your needs. Advanced encryption ensures the security of your recordings and device data at all times.
The Tapo H500 is an ideal solution for users looking for a subscription-free central security system with flexible expansion capabilities, smart automation support, and high-quality local monitoring.
Expandable Local Storage, No Monthly Fees: Provides massive, secure, and free local storage with built-in 16GB eMMC, expandable up to 16TB via HDD/SSD.
Enhanced AI Detection: Offers various free enhanced AI functions such as facial recognition, human, pet, and vehicle detection, and more.
Smart Home Ecosystem Hub: Capable of connecting up to 16 cameras and 64 sensors to build your smart home ecosystem.
Easy Wireless Setup: Connect your smart devices to the HomeBase via Wi-Fi, no complex wiring needed.
Supports Matter and ONVIF: Connects seamlessly with various smart devices, reducing the need for multiple hubs in your home.
Specifications:
| Interface |
1 HDMI Port, 1 DC Power Port |
| Adapter Input |
100-240V, 50/60Hz |
| Adapter Output |
12V, 2A |
| Ethernet Ports |
1* 10/100 Mbps |
| USB Support |
USB Ports: 1 USB-A Port for Data Transfer, 1 USB-C Port for Charging |
| Buttons |
1* Reset Button
1* Answer/Sync Button
1* Reject/Mute Button,
1* Volume Up Button
1* Volume
Down Button |
| Dimensions (W × D × H) |
6.31 × 3.89 × 3.28 in.
(160.20*98.82*83.21) mm |
| Local Storage |
Internal Storage: 16GB eMMC
Expanded Storage: 1 slot, 2.5-inch SATA HDD/SSD, up to 16TB (to be purchased separately) |
| Frequency |
5 GHz Wi-Fi (for Router)
2.4 GHz Wi-Fi (for Cameras)
Sub-1GHz Frequency Band: 863.35 MHz, 864.35 MHz, 868.35 MHz (for EU/UK)
920.9 MHz, 921.7 MHz, 922.3 MHz (for US/AU). |
| Security |
128-bit AES Encryption with SSL/TLS |
| Operating Humidity |
10%–90% RH, Non-condensing |
| Storage Humidity |
5%–90% RH, Non-condensing |
| Operating Temperature |
0 °C - 40 °C (32 °F - 104 °F) |
| Storage Temperature |
-20 °C ~ 60 °C (-4 °F ~ 140 °F) |
| Package Contents |
Tapo H500
Power Adapter
Screws
Quick Start Guide
Ethernet Cable |
*The specifications mentioned above are theoretical values based on product design. To provide accurate product information, specifications, and features, the manufacturer may make immediate adjustments to these specifications to align with actual product performance, specifications, indicators, and components. Product information is subject to these changes and adjustments without prior notice.
