IMOU Doorbell 3 Kit (4MP Wi-Fi Video Doorbell) | Imou
The IMOU DB-3EP-4M0W/DS3 Smart Doorbell is a Doorbell 3 Kit, a smart Wi-Fi video system designed to monitor your front door with a panoramic camera, two-way talk, smart motion alerts, night vision, and flexible power options. The kit includes a rechargeable battery-powered doorbell camera, plus an indoor chime/Wi-Fi range extender, giving you full visitor notifications and remote access from your smartphone.
✨ 4MP Panoramic Video — High-definition 4MP (1920x1920) camera with a wide fisheye lens gives you a panoramic view of the entrance area with no blind spots.
✨ Two-Way Audio & Talk Button — Built-in speaker and microphone let you talk with visitors in real-time from your phone or via the indoor chime.
✨ Smart Detection — Infrared motion sensor with person, package, and motion alerts for smarter notifications and reduced false alarms.
✨ Night Vision — Infrared illumination provides clear video capture in low-light conditions up to approximately 5 meters.
✨ Wireless & Flexible Power — Operates with the integrated rechargeable battery (5000 mAh) for easy installation; can also be hardwired to 8-24V AC depending on setup.
✨ Wi-Fi Connectivity — 2.4GHz wireless connection for remote viewing, alerts, and live video via the IMOU Life App.
✨ Expandable Storage — Supports local microSD card storage (up to 512GB) and optional cloud recording through the IMOU Protect service.
✨ Indoor Chime + Wi-Fi Extender Included — The kit includes an indoor chime unit that rings when the doorbell is pressed and also helps boost the Wi-Fi signal for reliable connectivity.
✨ Weather-Resistant Design — Designed to withstand typical outdoor conditions at your entryway.
📊 Specifications (Verified)
| Specification |
Detail |
| Model
|
IMOU DB-3EP-4M0W/DS3 (Doorbell 3 Kit) |
| Camera Resolution
|
4MP (1920x1920) Panoramic Fisheye Lens |
| Lens
|
0.98mm Fisheye Panoramic View |
| Night Vision
|
IR up to ~5 meters |
| Motion Detection
|
PIR motion sensor with motion/person/package alerts |
| Two-Way Audio
|
Yes — Microphone + Speaker |
| Connectivity
|
2.4GHz Wi-Fi |
| Storage
|
MicroSD card up to 512GB / Optional cloud service |
| Power Options
|
5000 mAh Rechargeable Battery or 8-24V AC Hardwired |
| Indoor Chime Included
|
Yes (Rings & acts as Wi-Fi range extender) |
| Operating Temperature
|
-20°C to +50°C |
| Outdoor Use
|
Yes — Weather-resistant |
| App Support
|
IMOU Life (Remote live view/alerts/playback) |
| Use Case
|
Front door/entryway security monitoring |
🏡 Key Features
✔ Wider Monitoring Coverage — Panoramic fisheye lens captures more of the entry and approach areas with fewer blind spots.
✔ Smart Alerts — Person and package detection helps focus alerts on important events rather than random motion.
✔ Flexible Power Options — Use as a battery-powered doorbell for easy installation or opt for hardwired power for continuous service.
✔ Two-Way Communication — Interact with visitors even when you're not home.
✔ Reliable Connectivity — The indoor chime acts as a Wi-Fi extender, improving signal strength and range.
✔ Day and Night Protection — Clear 24/7 video with infrared night vision.
🧠 Usage Scenarios
◆ Monitoring front door visitors
◆ Package and delivery alerts
◆ Family home security notifications and access
◆ Apartment or office entrance monitoring
◆ Remote live viewing and communication
