DSPPA 2x30W Mini Digital Amplifier with USB & Bluetooth | Mini60
DSPPA 2x30W Mini Digital Amplifier with USB & Bluetooth Mini60
MINI60 is a digital amplifier, also known as a mini PA amplifier, which is a small-sized sound amplification system featuring simplicity and high cost-effectiveness. This Class D amplifier can be used in small broadcasting systems, background music in small stores, and PA systems in classrooms. The digital amplifier system consists of a high-performance ARM processor main control unit and an energy-efficient, high-efficiency digital power amplifier circuit. This product can be abbreviated as a Bluetooth amplifier or a digital amplifier.
Features
● Bluetooth wireless playback.
● Recording function (AUX mode).
● USB/SD portable storage media playback.
● 1 stereo line input/output channel.
● External 12-24V DC power supply connection.
● Aluminum alloy housing, small and portable, sturdy and durable.
● Internationally accepted Phoenix jack for output is adopted to facilitate sound engineering construction.
● High-performance, stable stereo digital power amplifier with over-temperature, output overload, and short-circuit protection measures.
DSPPA 2x30W Mini Digital Amplifier with USB & Bluetooth | Mini60 Specifications:
Audio Performance
Rated Power: 2 × 30W
Frequency Response: 20Hz – 20kHz
THD: Less than 1%
Noise Level: 2mV
━━━━━━━━━━━━━━━━━━
Input Specifications
Line Input Sensitivity: 310mV
Mic Input Sensitivity: 10mV
━━━━━━━━━━━━━━━━━━
Power Specifications
Rated Voltage: 20V
Max Power Consumption: 90W
━━━━━━━━━━━━━━━━━━
Physical Specifications
Product Dimensions: 180 × 163 × 55mm (L × W × H)
Pack Size: 297 × 223 × 108mm
Master Carton Size: 608 × 458 × 338mm
Net Weight: 0.82kg
Gross Weight: 1.5kg
