Description
DSPPA Mini40 2x20W Mini Bluetooth Amplifier
Mini40 2x20W Mini Bluetooth Amplifier
The best Mini40 2x20W MiNi Bluetooth Amplifier is a single-channel digital amplifier, also known as a mono digital amplifier.
This Bluetooth amplifier has a 2x20W power output and a speaker output impedance ranging from 4 to 16 ohms. Class D technology ensures high power output efficiency with low power consumption.
This digital amplifier is concisely designed according to market demands, where customers prefer to listen to quiet and comfortable music. It features a compact design, Bluetooth connectivity, and low power consumption, making it suitable for hotels, small shops, and homes. This Bluetooth-enabled amplifier, available for sale, can be called a mini dual-channel amplifier or a two-channel amplifier.
Features
● Rounded corner frame, elegant and simple. Features a delicate frosting process and surface oxidation process, making it rust-resistant.
● Leading digital power amplification technology, differential input and output design, and two-stage filter processing circuit ensure an excellent signal-to-noise ratio, achieving high-fidelity full-range stereo reproduction, strong low frequency, and clear high frequency.
● Safe and reliable, with protection against over-temperature, over-current, and short-circuit, as well as soft-start technology to effectively protect the speaker.
● Easy to use, with two connection methods: Line and Bluetooth.
● Wide voltage design, applicable worldwide.
Mini40 Specifications
2x20W Mini Bluetooth Amplifier
━━━━━━━━━━━━━━━━━━
Audio Performance
Rated Power: 2 x 20W / 8Ω
Frequency Response: 20Hz – 20kHz
Total Harmonic Distortion: <0.3%
Signal-to-Noise Ratio: >82dB
Matched Impedance: 8Ω
━━━━━━━━━━━━━━━━━━
Input Specifications
Line Input Sensitivity: 0dB (1V)
Line Input Impedance: >10KΩ
━━━━━━━━━━━━━━━━━━
Bluetooth Specifications
Bluetooth Standard: BT 2.1 + EDR
Bluetooth Transmission Distance: Up to 10m
━━━━━━━━━━━━━━━━━━
Power Specifications
Power Supply: 220V / 50Hz / 60Hz
━━━━━━━━━━━━━━━━━━
Physical Specifications
Product Dimensions: 125 x 100 x 35 mm
Package Dimensions: 135 x 110 x 45 mm
Net Weight: 0.33 kg
Gross Weight: 0.35 kg
