Smart WiFi Bluetooth Streamer | DW01
DSPPA DW01 Smart WiFi Bluetooth Streamer
DW01 is a wireless streaming preamp that supports network and Bluetooth 5.0 connectivity. With DW01 and your existing stereo system, you can stream music from your smart devices, USB, NAS, or streaming services like Spotify, Tidal, and Qobuz in high quality via 4STREAM App, AirPlay, Bluetooth, or other compatible apps. DW01 supports high-quality music decoding up to 24-bit/192kHz sample rate, and also supports lossless audio formats such as FLAC, APE, and WAV. The DW01 can also be connected to a PC via a micro USB port and stream music directly from it. By adding more units to your home audio system, you can create a multi-room or multi-zone wireless audio system, giving you a new and unique music listening experience.
Features
◆ Stream music via network without distance limitation or via Bluetooth 5.0 up to 15 meters.
◆ Supports streaming protocols: Spotify connect, Airplay, Qplay, DLNA, UPnP.
◆ Supports streaming sources from online services, smart device memory, USB flash drive, NAS, Bluetooth, and line-in.
◆ Multi-room and multi-zone streaming enabled by multiple units connected to the same network.
◆ All music sources can be re-streamed synchronously with other models from us.
◆ Compatible with Airplay, Spotify Connect, Qplay, DLNA, UPnP, and third-party protocols and applications.
◆ Supports high-quality music streaming, sample rate decoding up to 24-bit, 192kHz.
◆ Spotify, Deezer, Tidal, Qobuz, iHeartRadio, Tuneln, Napster, many online streaming services built-in for app usage.
◆ Free app available for iOS and Android.
◆ Free global online update for new features.
◆ Full function remote control for use without a mobile phone.
◆ EQ adjustment via app or remote control.
◆ iTunes works with PC streaming.
◆ Connect to PC to stream music from PC digitally.
DSPPA DW01 Smart WiFi Audio Streamer Specifications:
━━━━━━━━━━━━━━━━━━
General
Type: Smart WiFi Audio Player
Designed to add wireless music streaming capability to existing stereo systems, speakers, and whole-home audio systems.
Supports high-resolution music playback and multi-room audio when multiple units are connected to the same network.
━━━━━━━━━━━━━━━━━━
Connectivity
Wireless Network: IEEE 802.11 b/g/n (2.4GHz)
Ethernet: 1 x RJ45 10/100 Mbps port
Bluetooth: Version 5.0
Bluetooth Range: Up to 15 meters
USB Host Port: USB 2.0
━━━━━━━━━━━━━━━━━━
Audio Specifications
Audio Output: 3.5mm analog mini jack
Audio Input: 3.5mm analog mini jack / Micro USB port
Frequency Response: 20 Hz - 20 kHz
Signal-to-Noise Ratio (SNR): 91 dB
Total Harmonic Distortion (THD): 0.03%
━━━━━━━━━━━━━━━━━━
Music and Streaming Formats
Supported Formats: FLAC / MP3 / AAC / AAC+ / ALAC / APE / WAV
Sample Rate Decoding: Up to 24-bit / 192 kHz
Supported Protocols:
AirPlay
DLNA
UPnP
Spotify Connect
Qplay
━━━━━━━━━━━━━━━━━━
Power
Power Input: 5V / 1A (Micro USB port)
━━━━━━━━━━━━━━━━━━
LED Indicators
Network: White - Power On / Wi-Fi Mode
BT: Blue – Bluetooth Mode
USB: Red - USB Mode
AUX: Green - Line-in Mode
━━━━━━━━━━━━━━━━━━
Physical Specifications
Dimensions: 116.2 × 64 × 22.6 mm
Weight: 0.2 kg
