DSPPA 13-25W(V) Outdoor High-Fidelity Horn Speaker | DSP163HD
DSPPA DSP163HD 13-25W High Fidelity Horn Speaker
The DSP163HD horn speaker is a high-fidelity horn speaker designed for use in 70/100V public address systems. The 70V/100V voltage transmission technology reduces line losses over long distances and allows multiple loudspeakers to be easily connected in parallel. It features an IPX6 waterproof rating, making it suitable for outdoor use; clear sound, high sensitivity; waterproof, made of high-quality aluminum alloy, durable for long-term use.
Made of durable aluminum alloy, it is lightweight and rust-resistant.
Streamlined appearance, beautiful design, sophisticated engineering.
It is the ideal choice for industrial and commercial applications in outdoor areas of train stations, shopping malls, parking lots, factories, and places of worship (churches and mosques) where background music and paging systems are needed.
Features
◆ Outputs: 13W/70V and 25W/100V
◆ Suitable for outdoor use
◆ Built-in 100V/70V transformer
◆ Max SPL: 117±2dB
◆ Wide frequency response range: 200Hz - 15KHz
◆ High sensitivity: 103±2dB
◆ Equipped with mounting brackets
DSPPA DSP163HD 13-25W High Fidelity Horn Speaker Specifications:
Outdoor High Fidelity Horn Speaker - 13W / 25W (70V / 100V)
━━━━━━━━━━━━━━━━━━
General
Type: Outdoor High Fidelity Horn Speaker
Built-in 70V / 100V Transformer (Constant Voltage Line)
Weatherproof and Durable Design - Suitable for Outdoor Use
━━━━━━━━━━━━━━━━━━
Power and Performance
Rated Power:
13W at 70V
25W at 100V
Sensitivity (1W / 1m): 103 ±2 dB
Max SPL (at 1m): 117 ±2 dB
Frequency Response: 200 Hz - 15 kHz
━━━━━━━━━━━━━━━━━━
Electrical Specifications
Input Voltage: 70V / 100V, Constant Voltage Line
Built-in Transformer for:
Long-Distance Transmission
Low Signal Loss
Easy Parallel Connection of Multiple Speakers
━━━━━━━━━━━━━━━━━━
Installation and Construction
Includes Mounting Bracket for Wall Installation
Weatherproof Design for Outdoor Public Address Systems
━━━━━━━━━━━━━━━━━━
Physical Specifications
Dimensions (L x W x H): 500 x 415 x 500 mm
Weight: Approximately 3.3 kg
