Parental Controls: Manage when and how connected devices can access the internet
Quality of Service: Prioritizes devices or applications to deliver faster performance where you need it
Security: Protects your home network with SPI firewalls and WPA2 encryption
IPTV: Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming
Multi-language interface: Provides easy setup in six languages
IPv6: Compatible with IPv6 (Internet Protocol Version 6)
TP-Link Archer C58HP – AC1750 High Power Dual-Band Router
Wireless
Standards
◆ Wi-Fi 5 (802.11ac)
◆ IEEE 802.11ac/n/a – 5 GHz
◆ IEEE 802.11n/b/g – 2.4 GHz
Wi-Fi Speeds (AC1750)
◆ 5 GHz: 1300 Mbps
◆ 2.4 GHz: 450 Mbps
Coverage
◆ Suitable for 4-bedroom homes
◆ 3x 9dBi high-gain detachable antennas
◆ High power FEM module for stronger signal transmission
Capacity & Modes
◆ Dual-band
◆ Medium capacity
◆ Operating modes:
– Router Mode
– Access Point Mode
– Range Extender Mode
Security
◆ SPI Firewall
◆ Access Control
◆ IP & MAC Address Binding
◆ Application Layer Gateway
◆ Guest Network (2.4 GHz & 5 GHz)
◆ VPN Server: OpenVPN / PPTP
◆ Wi-Fi Encryption: WEP / WPA / WPA2 / WPA/WPA2-Enterprise (802.1x)
Hardware
◆ Processor: Single-Core CPU
◆ 1x 10/100 Mbps WAN port
◆ 4x 10/100 Mbps LAN ports
◆ Buttons:
– Wi-Fi On/Off
– Power On/Off
– WPS
- Reset
◆ Power: 12V ⎓ 1.5A
Software
Protocols
◆ IPv4
◆ IPv6
Parental Controls
◆ URL Filtering
◆ Time Controls
WAN Types
◆ Dynamic IP
◆ Static IP
◆ PPPoE
◆ PPTP
◆ L2TP
Quality of Service
◆ QoS by Device
NAT Forwarding
◆ Virtual Server
◆ Port Forwarding
◆ Port Triggering
◆ DMZ
◆ UPnP
IPTV
◆ IGMP Proxy
◆ IGMP Snooping
DHCP
◆ Server
◆ Address Reservation
◆ DHCP Client List
DDNS
◆ No-IP
◆ DynDNS
Management
◆ Tether App
◆ Web UI
Test Data
Transmit Power
◆ CE: <20 dBm
◆ FCC: <30 dBm
Receive Sensitivity
◆ 867 Mbps: -61 dBm @ 10% PER
◆ 450 Mbps: -71 dBm @ 10% PER
◆ 54 Mbps: -77 dBm @ 10% PER
◆ 11 Mbps: -89 dBm @8% PER
◆ 6 Mbps: -89 dBm @ 10% PER
◆ 1 Mbps: -97 dBm @8% PER
Physical
◆ Dimensions: 249 × 217 × 54 mm
◆ Operating Temperature: 0°C to 40°C
◆ Storage Temperature: -40°C to 70°C
◆ Operating Humidity: 10%~90% non-condensing
◆ Storage Humidity: 5%~90% non-condensing
◆ Certifications: FCC, CE, RoHS
Package Contents
◆ Archer C58HP Router
◆ Power Adapter
◆ RJ45 Ethernet Cable
◆ Quick Installation Guide
