الكبلنج/الكاملوك

Product Description: ● 3 inch Type C Aluminum Female Cam and Groove Coupler x Hose Shank. How to use: ● To connect, insert the 3" Type C over a 3" Male Adapter and then simultaneously close the two cam lever arms. ● To disconnect, lift up the cam handles and uncouple the two fittings. To Install: ● Insert the Hose Barb into a 3" Hose and fasten it in place with a crimp collar or hose clamp. Will Connect with: ● The coupler portion will couple with a 3" Male Adapter. ● The Hose Shank will connect to a 3" Hose. (Outer Diameter) Used to: ● Install a 3" Female Cam & Groove into a 3" Hose End.  Jump Size: ●  For more ways to change connection size (jump-size) scroll down to"Upsell Products". Material: ● Constructed out of Aluminum. ● For other materials scroll down to "Related Products".   Specifications: More Information Size 3" Part Number C300-AL Material Aluminum Handles Stainless Steel 304 Gasket Buna-N (Buna Nitrile) Thread 3" Hose Shank Working Pressure 125 PSI

Product Description: ● 3 inch Type E Aluminum Male Cam and Groove Coupler x Hose Shank. How to use: ● To connect, slide the 3" Type E into a 3" Female Coupler and then close the two cam handles simultaneously. ● To disconnect, lift up the cam lever arms and uncouple the two hose fittings. To Install:  ● Slide the Hose Barb into a 3" Hose and fasten it with a crimp collar or with hose clamps. Will Connect with: ● The adapter portion will couple with a 3" Female Coupler. ● The Hose Barb will connect to a 3" Hose. (Outer Diameter) Used to: ● Install a 3" Male Cam & Groove into a 3" Hose End.  Jump Size: ●  For more ways to change connection size (jump-size) scroll down to"Upsell Products". Material: ● Constructed out of Aluminum. ● For other materials scroll down to "Related Products".   Specifications: More Information Size 3" Part Number E300-AL Material Aluminum Thread 3" Hose Barb Working Pressure 125 PSI

Product Description: ● 3 inch Type DP Aluminum Male Cam and Groove Dust Plug. How to use: ● To connect, slide the 3" Type DP into a 3" Female Coupler and then close the two cam handles. ● To disconnect, lift up the cam lever arms and uncouple the two fittings. To Install: ● Slide the 3" Cam & Groove Dust Plug into a 3" Female Coupler and then close the two cam lever handles. Used to: ● Seal off and close a 3" Female Coupler and to prevent contaminates and dust from entering. More Options : ● For more examples the 3" Quick Connect Dust Plug is used on scroll down "Upsell Products". Material: ● Constructed out of Aluminum. ● For other materials scroll down to "Related Products".   Specifications: More Information Size 3" Part Number DP300-AL Material Aluminum Thread 3" Male Plug End Working Pressure Not for pressure (safety concerns)

Product Description: ● 2 inch Type A Aluminum Male Cam and Groove Adapter x Female NPT Thread. How to use: ● To connect, insert the 2" Type A into a 2" Female Coupler and then simultaneously close the two cam lever arms. ● To disconnect, lift up the cam handles and uncouple the two fittings. To Install: ● Thread the Female NPT portion onto a 2" Male NPT Thread. Will Connect with: ● The adapter portion will couple with a 2" Female Coupler. ● The thread will connect to a 2" Male NPT Thread. (National Pipe Thread) Used to: ● Connect a 2" Male Cam & Groove onto a 2" Male NPT Thread.  ● Connect with a 2" Female Coupling. Changing Thread Size: ● For more ways to change the 2" connection size, to jump size, scroll down to "Upsell Products" Strainers: ● The 2" female threads can accept Disc Strainers and connect to a Sight Glass, for examples scroll down to "Upsell Products". Material: ● Constructed out of Aluminum. ● For other materials scroll down to "Related Products".   Specifications: More Information Size 2" Part Number A200-AL Material Aluminum Thread 2" Female NPT Working Pressure 250 PSI   Product Description: ● 3 inch Type A Aluminum Male Cam and Groove Adapter x Female NPT Thread. How to use: ● To connect, Insert the 3" Type A into a 3" Female Coupler and then simultaneously close the two cam lever arms. ● To disconnect, lift up the cam handles and uncouple the two fittings. To Install: ● Thread the Female NPT portion onto a 3" Male NPT Thread. Will Connect with: ● The adapter portion will couple with a 3" Female Coupler. ● The thread will connect to a 3" Male NPT Thread. (National Pipe Thread) Used to: ● Connect a 3" Male Cam & Groove onto a 3" Male NPT Thread.  ● Connect with a 3" Female Coupling. Material: ● Constructed out of Aluminum. ● For other materials scroll down to "Related Products".   Specifications: More Information Size 3" Part Number A300-AL Material Aluminum Thread 3" Female NPT Working Pressure 125 PSI

Product Description: ● 1-1/2 inch Type F Aluminum Male Cam and Groove Adapter x Male NPT Thread. How to use: ● To connect, insert the 1-1/2" Type F into a 1-1/2" Female Coupler and then close the two cam handles simultaneously. ● To disconnect, lift up the cam lever arms and uncouple the two fittings. To Install: ● Thread the Male NPT portion into a 1-1/2" Female NPT Thread. Will Connect with: ● The adapter portion will couple with a 1-1/2" Female Coupler. ● The thread will connect to a 1-1/2" Female NPT Thread. (National Pipe Thread) Used to: ● Connect a 1-1/2" Male Cam & Groove onto a 1-1/2" Female NPT Thread.  ● Connect with a 1-1/2" Female Coupling. Jump Size and Changing Thread Size: ● For more ways to change thread size and connection size (jump-size) scroll down to "Upsell Products". Commonly installed into:  ● For 1-1/2" ball valve options scroll down to "Upsell Products". Material: ● Constructed out of Aluminum. ● For other materials scroll down to "Related Products".   Specifications: More Information Size 1-1/2" Part Number F150-AL Material Aluminum Thread 1-1/2" Male NPT Working Pressure 250 PSI

Product Description: ● 4 inch Type B Aluminum Female Cam and Groove Coupler x Male NPT Thread. How to use: ● To connect, insert the 4" Type B into a 4" Male Adapter and then simultaneously close the two cam lever arms. ● To disconnect, lift up the cam handles and uncouple the two fittings. To Install: ● Thread the Male NPT portion into a 4" Female NPT Thread. Will Connect with: ● The coupler portion will couple with a 4" Male Adapter. ● The thread will connect to a 4" Female NPT Thread. (National Pipe Thread) Used to: ● Install a 4" Female Cam & Groove into a 4" Female NPT Thread.  Jump Size: ● For more ways to change connection size (jump-size) scroll down to "Upsell Products". Material: ● Constructed out of Aluminum. ● For other materials scroll down to "Related Products".   Specifications: More Information Size 4" Part Number B400-AL Material Aluminum Handles Stainless Steel 304 Gasket Buna-N (Buna Nitrile) Thread 4" Male NPT Working Pressure 100 PSI

السعة: 10 سم³ نوع التوصيل: مقاس 1/4 بوصة دقة التصفية للفلتر: حوالي 40 ميكرون المادة المصفّية: ألياف (فلتر أليافي) الوزن: تقريبًا 0.10 كجم الاستخدام يُستخدم هذا الـوصلة  لإضافة كمية معينة من الزيت بشكل منتظم لأدوات الهواء أو أنظمة التشحيم يُركّب غالبًا بخط الهواء لضمان أن أجزاء مثل البُكر، البِراغي، أو المكونات المتحركة تتلقى زيتًا لتقليل الاحتكاك والتآكل

Product Description JRD TAKESHI FEMALE PLUG

Product Description Female Fitting
